6-6
6. Wiring Diagram
6-4. Connector Functions
Connector Functions
CN303(FRC-M : CN506) <-> CN1 The LVDS signal transfered from FRC Board to Panel(41pin).
* defective symptom : abnormal Picture
CN304(FRC-M : CN505) <-> CN2 The LVDS signal transfered from FRC Board to Panel(51pin).
* defective symptom : abnormal Picture
CN2702 <-> CN301(FRC-M : CN502) The LVDS signal transfered from Main Board to FRC Board.
* defective symptom : No picture
CN1101 <-> CN801 Supply main power from IP board to Main Board.
* defective symptom : No picture, diable Power On/Off
CN2703 <-> CN1803 Supply dimming power from IP board to Main Board.
* defective symptom : No picture but normal sound
CN1806 <-> CN125 Supply power and siganl from IP board to Panel Driver.
* defective symptom : No picture but normal sound
CN1601 <-> CN105 The signal transfered from Main Board to Side-AV.
* defective symptom : cannot any functions of SIDE AV
CN1808 <-> CN127 Supply power from IP board to Driver Board(left).
* defective symptom : No picture but normal sound
