Samsung LE40F86BD - 5-2-1. LE46 F86 BD Parts List

5-4
5. Exploded View & Part List
5-2-1. LE46F86BD Parts List
Location No. Code No. Description & Specifi cation Q’ty S.A/S.N.A Remark
T0275 BN96-05490A ASSY MISC P-INLET 1 S.N.A
M0596 BN94-01442A ASSY PCB MISC-FRC 1 S.A
T0003 BN96-04056C ASSY COVER P-FRONT;46F71,UO,PC+ABS,V0,BK 1 S.A
M0112 BN96-06040A ASSY SPEAKER P;8ohm,Peony/Rose 46/52,Woofer 1 S.A
M0215 BN07-00395A LCD-PANEL;V460H1-L01,8bit,46inch,16.7M,1 1 S.A
T0047 BN96-03420E ASSY BRACKET P-PANEL;46M71,UO,-,-,-,MOSE 1 S.N.A
M0027 BN96-04057A ASSY STAND P-BASE;46M7,-,ABS+PMMA,HB,BK2 1 S.A
M0115 BN61-02538A BRACKET-STAND LINK;46M7,SECC,T1.6 1 S.N.A
M0146 BN61-02539B BRACKET-PANEL TOP;46F71,SECC,T1.6,MOSEL- 2 S.N.A
T0175 BN96-06045A ASSY SPEAKER P,8ohm,Peony/Rose 46/52 Mid-Range 2 S.A
T0023 BN96-06039A ASSY SPEAKER P,8ohm,Peony/Rose 46/52 Tweeter 2 S.A
M0014 BN94-01358A ASSY PCB MAIN-CMO;LNT466FX/XAA 1 S.A
M0174 BN44-00168A IP BOARD;SIP460A,46” TULIP,30mA,75mA,150 1 S.A
T0172 BN61-03403A HOLDER WALL;PEONY 46,HIPS V0,BK500 2 S.N.A
M0175 BN61-02875D HOLDER-SIDE AV 1 S.A
T0603 BN63-03657A SHIELD-PCB MAIN;MOSEL 3 46”,SECC T0.5 1 S.N.A
M0013 BN96-03414C ASSY COVER P-REAR;46F71,UO,HIPS,V0,BK500 1 S.A
