5-16
5. Exploded View & Part List
Level Location No. Code No. Description & Specifi cation Q’ty SA/SNA Remark
....4 T0087 1203-001815 IC-POSI.FIXED REG.;78M09,TO-252,3P,-,PLA 1 S.A
....4 T0087 1203-002842 IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P 1 S.A
....4 T0087 1203-002855 IC-POSI.FIXED REG.;MC33269DTRK-5.0,DPRK, 1 S.A
....4 T0087 1203-002898 IC-POSI.FIXED REG.;G950T45R,T0-252,3P,6. 1 S.A
....4 T0087 1203-002898 IC-POSI.FIXED REG.;G950T45R,T0-252,3P,6. 1 S.A
....4 IC3205_NHU 1203-003394 IC-POWER SUPERVISOR;MIC2544-1YM,SOP,8P,4 1 S.A
....4 IC3606_EU 1203-003394 IC-POWER SUPERVISOR;MIC2544-1YM,SOP,8P,4 1 S.A
....4 T0087 1203-003696 IC-POSI.FIXED REG.;NCP1117DT18T5G,DPAK,3 1 S.A
....4 T0087 1203-003696 IC-POSI.FIXED REG.;NCP1117DT18T5G,DPAK,3 1 S.A
....4 IC2104 1203-004363 IC-VOL. DETECTOR;RT9818C-29PV,SOT-23,3P, 1 S.A
....4 IC1405 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A
....4 IC1406 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A
....4 IC3003 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A
....4 T0170 1203-004868 IC-SWITCH VOL. REG.;MP2363,SOIC,8P,4.9x3 1 S.A
....4 T0170 1203-004868 IC-SWITCH VOL. REG.;MP2363,SOIC,8P,4.9x3 1 S.A
....4 T0170 1203-004868 IC-SWITCH VOL. REG.;MP2363,SOIC,8P,4.9x3 1 S.A
....4 T0170 1203-004868 IC-SWITCH VOL. REG.;MP2363,SOIC,8P,4.9x3 1 S.A
....4 IC1201 1204-002719 IC-AUDIO PROCESSOR;SGTV5810,LQFP,100P,14 1 S.A
....4 IC118 1204-002724 IC-VIDEO PROCESS;SVP-WX68,BGA,336P,27x27 1 S.A
....4 IC118 1204-002729 IC-VIDEO PROCESS;S4LF119X01,PBGA,208P,17 1 S.A
....4 IC3001 1204-002782 IC-DECODER;OM7029EL/C1,LBGA,260P,19x19mm 1 S.A
....4 IC2401_WX 1205-003185 IC-RECEIVER;MST3560M-LF-170,PQFP,128P,20 1 S.A
....4 IC1407 1205-003201 IC-BUS SWITCH;TC7WB125FK,SSOP,8P,2x2.3mm 1 S.A
....4 IC1401_WX 1205-003256 IC-RECEIVER;SiI9125CTU(Rev0.3),TQFP,144P 1 S.A
....4 D1611 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 D1620 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 D1641 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 D1815 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 D1816 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 D1817 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 D2102 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 R1418 2007-000042 R-CHIP;499ohm,1%,1/10W,TP,1608 1 S.A
....4 R2637 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2729 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2730 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2104 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2105 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2108 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2109 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2110 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2111 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2112 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2113_LCD 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2130 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2131 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2144 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R3232 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2709 2007-000060 R-CHIP;100Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1120 2007-000067 R-CHIP;15Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1127 2007-000067 R-CHIP;15Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1144 2007-000067 R-CHIP;15Kohm,1%,1/10W,TP,1608 1 S.A
