Samsung LE40F86BD - 2. Product specifications; 2-1. Feature & Specifications

2-1
2. Product specications
2. Product specications
2-1. Feature & Specications
Model LE40F86BD
Feature
Digital-TV, RF, 3-HDMI, 1-Component, 1-AV, 1-S-Video, USB2.0(WISELINK), D-SUB
Brightness : 500cd/m
2
Contrast Ratio : 8000:1
Response time : 6ms
Dynamic contrast, Super-PVA
PIP(in HDMI 1, 2, 3, Component 1, PC Mode and Sub picture is available only in TV analog mode)
�
�
�
�
�
�
Specications
Item Description
LCD Panel TFT-LCD panel, RGB vertical stripe, SPVA mode, normaly black,
40-Inch viewable, 0.46125(H) x 0.46125(W) x 3 mm pixel pitch
Scanning Frequency Horizontal : 30 kHz ~ 80 kHz (Automatic)
Vertical : 56 Hz ~ 75 Hz (Automatic)
Display Colors 16.7 million colors
Maximum resolution Horizontal : 1920 Pixels
Vertical : 1080 Pixels
Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω , internally terminated
Input Sync Signal H/V Separate, TTL, P. or N.
Maximum Pixel Clock rate 310MHz
Active Display
Horizontal/Vertical 34.84 x 19.59 inches (885.168 (H) x 497.664 (V) mm)
AC power voltage & Frequency AC 110V ~ 240V, 50/60Hz
Power Consumption <245 W ( < 1W, stand by )
Dimensions
43.08 x 11.41 x 26.59 inches (1094.3 x 289.9 x 675.4mm) with stand
43.08 x 4.04 x 23.9 inches (1094.3 x 102.8 x 607.3 mm) without stand
Set (W x D x H)
Weight (Set) 52.24 lbs (23.7kg)
TV System Tuning Frequency Synthesize (Refer to detailed Frequency Table)
System DVB-T, PAL, SECAM, NT4.43
Sound BG, DK, NICAM, MPEG1
Environmental Considerations Operating Temperature : 50˚F ~ 104˚F (10˚C ~ 40˚C)
Operating Humidity : 10% ~ 80%, non-condensing
Storage temperature : -13˚F ~ 113˚F (-25˚C ~ 45˚C)
Storage Humidity : 5% ~ 95%, non-condensing
Environmental Considerations - MAX Internal speaker Out : Right => 10W, Left => 10W
- BASS Control Range : -8 dB ~ + 8dB
- TREBLE Control Range : -8 dB ~ +8 dB
- Headphone Out : 10 mW MAX
- Output Frequency : RF : 80 Hz ~ 15 kHz
A/V : 80 Hz ~ 20 kHz
Note: Anynet+, WISELINK
