5-27
5. Exploded View & Part List
Level Location No. Code No. Description & Specifi cation Q’ty SA/SNA Remark
....4 R3020 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R3022 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R3028 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R3029 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R3057 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R3427 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R3429 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R3447 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R3448 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R3450 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R3466_EU 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R3467_EU 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R3468_EU 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R2401_WX 2007-000118 R-CHIP;390ohm,5%,1/10W,TP,1608 1 S.A
....4 R1470 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608 1 S.A
....4 R2143 2007-000120 R-CHIP;680ohm,5%,1/10W,TP,1608 1 S.A
....4 R3446 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1128_LCD 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1465 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R2146 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1116 2007-000129 R-CHIP;27Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1125 2007-000129 R-CHIP;27Kohm,5%,1/10W,TP,1608 1 S.A
....4 R2135 2007-000129 R-CHIP;27Kohm,5%,1/10W,TP,1608 1 S.A
....4 R2711 2007-000133 R-CHIP;330Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1108 2007-000208 R-CHIP;1.1Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1421_WX 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1422_WX 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1424_WX 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1425_WX 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1426_WX 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1429_WX 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1442_WX 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1443_WX 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1444_WX 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1445_WX 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1446_WX 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1447_WX 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1448_WX 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1449_WX 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1611 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1612 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1632 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1633 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1634 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1636 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1638 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1639 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1641 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1642 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1645 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R1646 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
