2 Product Specifications
2-4
2-4 LE46M86BDX/LE46M86BCX Specifications
Item
LCD Panel
Scanning Frequency
Display Colors
Description
LTA460HT-LH2, SPVA 92% ZBD, 46inch FHD, 0.53025(H) x 0.53025(W) x 3mm
T460HW02 AMVA 92% 46inch FHD, 1018.08(H) x 572.67(V)mm
Horizontal : 30 kHz ~ 80 kHz (Automatic) / Vertical : 56 Hz ~ 75 Hz (Automatic)
16.7 M colours
Analog 0.7 Vp-p ± 5% positive at 75Ω , internally terminated
Maximum Resolution
Input Video Signal
166.8 MHz
Maximum Pixel Clock rate
AC 220 ~ 240 V, 50/60 Hz
AC power voltage & Frequencya
260 W ＜1W
Power Consumption
75Ω
Antenna Input
-MAX Internal speaker Out : Right : 10W / Left : 10W
-BASS Control Range : -8 dB ~ + 8dB
-TREBLE Control Range : -8 dB ~ +8 dB
-Headphone Out : 10 mW MAX
-Output Frequency : RF : 80 Hz ~ 15 kHz
A/V : 80 Hz ~ 20 kHz
Sound Characteristic
TV System
Environmental Considerations
Tuning
System
Sound
Frequency Synthesize
PAL, SECEM
MONO, STEREO, NICAM
30Kg
Weight
Set(After installation Stand)
1106 x 104 x 706 mm / Without stand
1106 x 326 x 768 mm / After installation Stand
Operating Temperature : 50°F ~ 104°F (10°C ~ 40°C)
Operating Humidity : 10 % ~ 80 %
Storage Temperature : -4°F ~ 113°F (-20°C ~ 45°C)
Storage Humidity : 5 % ~ 95 %
Dimensions(W x D x H)
Set
819.36(H) mm / 460.89(V) mm
Active Display
Horizontal/Vertical
Horizontal : 1920 Pixels
Vertical : 1080 Pixels
Input Sync Signal
Type : Seperate H/V
Level : TTL level
