5-34Samsung Electronics
Exploded Views and Parts List
■
Parts List
Q'TY
SA/SNA
No. Code No. Description Specification
MH060FXEA3B MH070FXEA4B MH080FXEA4B
1 DB90-03918B ASS’Y CABI FRONT-TOTAL ASS’Y 111SNA
1-1 DB63-00831A GUARD FAN-P PP,SC-90073R 1 1 1 SA
2 DB90-03278C ASS’Y BASE OUT-TOTAL ASS’Y 111SNA
3 DB67-00861A FAN PROFELLER AS-GF 20% 1 1 1 SNA
4 DB31-00512A MOTOR FAN 65A,130W,DC 310V 1 1 1 SA
5 DB61-20094D BASE MOTOR SGCC-M 1 1 1 SNA
6 DB94-01750A ASS’Y PARTITION ASS’Y 111SNA
7 DB96-08873A ASS’Y COND ASS’Y 1 - - SNA
DB96-09223A ASS’Y COND ASS’Y - 1 1 SNA
8 DB71-00122A BAR STEEL HSWR 1 1 1 SNA
9 DB90-03920A ASS’Y CABINET-SIDE RH ASS’Y 111SNA
10 DB90-03919A ASS’Y CABI BACK-RH ABS 1 1 1 SNA
11 DB90-03275A ASS’Y CABINET UP ASS’Y 111SNA
12 DB90-03932A ASS’Y CABINET-SIDE LF PAINT ASS’Y 111SNA
13 G8T200FUAEW COMPRESSOR BLDC INVERTER 1 - - SA
G8T260FUAEW COMPRESSOR BLDC INVERTER - 1 1 SA
13-1 DB63-00763A GROMMET ISOLATOR NR 3 3 3 SNA
14 DB96-08915A ASS’Y 4WAY VALVE ASS’Y 1 - - SNA
DB96-09230A ASS’Y 4WAY VALVE ASS’Y - 1 1 SNA
15 DB96-08922A ASS’Y VALVE ASS’Y 1 - - SNA
DB96-09236A ASS’Y VALVE ASS’Y - 1 1 SNA
16 DB93-05697F ASS’Y CONTROL OUT ASS’Y1--SA
DB93-05697E ASS’Y CONTROL OUT ASS’Y-1-SA
DB93-05697D ASS’Y CONTROL OUT ASS’Y--1SA
16-1 DB93-05700F ASS’Y PCB MAIN ASS’Y1--SA
DB93-05700E ASS’Y PCB MAIN ASS’Y-1-SA
DB93-05700D ASS’Y PCB MAIN ASS’Y--1SA
16-2 DB61-02974A CASE CONTROL COVER ABS 1 1 1 SA
16-3 DB62-05315A HEAT SINK 1 1 1 SNA
16-4 DB93-04745D ASS’Y PCB SUB EMI ASS’Y 1 - - SNA
DB93-04745C ASS’Y PCB SUB EMI ASS’Y - 1 1 SNA
16-5 DB61-02973A CASE CONTROL BASE ABS 1 1 1 SNA
16-6 DB70-00910A PLATE-CONTROL OUT SGCC-M 1 1 1 SC
16-7 DB95-01180B ASS’Y-TERMINAL BLOCK SGCC-M 1 1 1 SC
16-8 DB65-00181D TERMINAL BLOCK BLK 1 1 1 SC
16-9 DB65-00181F TERMINAL BLOCK BLK - 1 1 SC
DB65-00181E TERMINAL BLOCK BLK 1 - - SC
16-10 DB95-01180A ASS’Y-TERMINAL BLOCK ASS’Y 111SC
16-11 DB93-06290A ASS’Y PCB SUB-DISPLAY ASS’Y 111SA
16-12 DB61-01097A HOLDER WIRE CLAMP ABS 2 2 2 SA
17 DB27-00042A REACTOR 15A, 50Hz 1 - - SA
DB27-00043A REACTOR 20A, 50Hz - 1 1 SA
18 DB32-00175B THERMISTOR COND 103AT,204CTB 1 1 1 SC
19 DB32-00176C
THERMISTOR WIRE OUT/DISCHARGE
103AT,204CTB 1 1 1 SC
20 DB64-01231A HANDLE ABS 1 1 1 SA
