Samsung Electronics 6-7

PCB Diagram

6-4-1 Pin Connection

1 CON1

TAPE DECK Status

Pin No. Signal

1 12V

2 REC SW(FWD)

3 GND

4 PHOTO OUT

5 SOL

6 HALF SW

7 REC SW(RVS)

2 JCON10

TAPE DECK Control/Signal Connector

Pin No. Signal

1 SOL

2 TAPE_MUTE

3 REC

4 REC/M

5 MOTOR

6 HALL

7 A/D3

8 A/D4

9 MB+

10 GND

11 +12V

12 GND

13 REC-R

14 REC-L

15 OUT-R

16 GND

17 OUT-L

3 JCON11

TAPE DECK Motor Control

Pin No. Signal

1 P/B-L

2 R/P-L

3 P/B-R

4 R/P-R

5 E+

6 E-
