Samsung Electronics 6-15
PCB Diagram
6-8-1 Pin Connection
1 CN12
Motor Control
Pin No. Signal
1 TM+
2 TM-
3 ND
4 OPSW
5 CLSW
6 SL-
7 SL+
8 SP+
9 SP-
2 RFCON1
DECK Data
Pin No. Signal
1 CD-VR
2 MPD
3 CD-LD
4 LD-GND
5 SW
6 F-
7 T+
8 T-
9 F+
10 B
11 C
12 D
13 A
14 E
15 F
16 Vcc
17 Vref
18 GND
19 DVD-VR
20 PD
21 DVD-LD
22 RFCON1
23 H-Vcc
3 JCW2
MPEG Power
Pin No. Signal
1 S12V
2 AGND
3 -12V
4 GND
5 +5V
6 +3.3V
4 JCW1
MPEG PCB Connector (Data)
Pin No. Signal
1 AGND
2 CVBS
3 VGND
4 VGND
5 VGND
6 U_TXD
7 U-ACK
8 U_STB
9 U_RXD
10 MRST
11 DACCLK
12 DACDT
13 DACCE
14 MIC_CLK
15 MIC_DATA
16 MIC_SENS
17 HP_SENS
18 P_CHK
19 AGND
20 MIC_SIGN
21 HP_L
22 HP_R
23 AUX-R
24 AUX-L
25 CD_L
26 CD_R
27 AGND
