Switch Setting and Testing Operation (cont.)
ROTARY SWITCH “SW02 ” POSITION ACCORDING TO REFRIGERANT CIRCUIT
CONNECTED (0=A;1=B;2=C;3=D;4=E )
INSTALLATION TEST MODE (with all indoor units functioning)
Please do cool mode try-run or heat mode try run.
Cool mode try-run :Push the [K2 ] button three times.
Heat mode try-run :Push the [K2 ] button once.
*OEPPS6OJU
48
0
"UU"
1
"UU#
2
"UU$
3
"UU%
4
"UU&
"VOJU
#VOJU
$VOJU
%VOJU
&VOJU
065%0036/*5
