2-36 Samsung Electronics
MH FMEA
Item Descriptions Q'TYCode-No. Remark
Indoor
Unit
Pattern sheet DB69-01369A 1
Insulation cover drain DB62-01959A 1
Insulation-drain DB62-01960B 1
Insulation cover band DB72-00109J 1
Insulation pipe DB72-00109G 1
Insulation-Install inlet DB72-00143E
Insulation-drain DB72-00143G
Cable-tie DB65-00191A 5
Ass'y drain hose DB94-01270D 1
M4x12 tapped Screw 6002-000213 4
1
(MH052FMEA
only)
2
(MH030FMEA/
MH035FMEA)
1
(MH052FMEA)
Installation manual DB98-27682A 1
Safety net DB63-01372A 1
The design and shape can be changed according to the model.
Accessories(cont.)
To Next Page
