3-6 Samsung Electronics
No Parts Procedure Remark
1 Common Work
&
Control Out
1) Loosen 1 fixing screw(CCW)of the
Cover-Valve. (Use +Screw Driver.)
2) Loosen each 9 screws(CCW)on cabi
top.
(Use +Screw Driver.)
3) Loosen 2 screw(CCW)fixed to assemble
Plate Control Out with Cabinet-Side RH.
(Use +Screw Driver.)
4) Loosen 10 fixing screws(CCW)on
Cabinet-Side RH.
(Use +Screw Driver.)
3-1-2 RJ052F3HXEA/AJ052FCJ3EH
You must turn off the Power before
disassembly.
