6. Material List
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
R530/R730
Level Code Assembled EA Description Spec. Service
......3 3711-000922 J516 1 HEADER-BOARD TO
CABLE
BOX,4P,1R,1.25mm,SMD-A,SN,WHT
......3 3711-002046 J501 1 HEADER-BOARD TO
CABLE
BOX,12P,1R,1.25mm,SMD-S,SN,WHT
......3 3711-007011 J503 1 HEADER-BATTERY NOWALL,7P,1R,2.5mm,BATTERY TYPE,AU,BLK
......3 3722-002588 J520 1 JACK-PHONE 6P,AU,BLK,ANGLE
......3 3722-002588 J521 1 JACK-PHONE 6P,AU,BLK,ANGLE
......3 3722-002767 J519 1 JACK-USB 4P/1C,AU,BLK,ANGLE,A
......3 3722-002865 J511 1 JACK-MODULAR 8P/8C,STANDARD,N,SMD-A,GRN/YEL,Au,1PORT
......3 3722-002925 J502 1 JACK-USB 4P/2C,AUF,BLK,ANGLE-OFFSET,A,-
......3 3722-002997 J500 1 JACK-DC POWER 3P,5.6PI,AUF,BLK
......3 4309-001022 J522 1 BATTERY-HOLDER CELL,PIN,25.4mm,28.45x19.30x4.98mm,TP,1.1g,1.1g
......3 BA09-00021A U504 1 IC MICOM MEC1308-NU,-,128,3.3V,32.768KHz,Romless,16M,8,VTQFP,TRAY,
14mm*14mm*1.0mm,8,0~70,-,0,VTQFP,-
......3 BA41-01178A PCB 1 PCB MAIN Bremen-UL,FR-4,6L,-,1.1T,w238*L210mm,-,-,-,OSP,NANYA,-
......3 BA61-01090A M500 1 SUPPORT-MINICARD RIMINI,ALLOY,T1.5,W4.5,L1.5mm,NTR,-,-
......3 BA61-01090A M501 1 SUPPORT-MINICARD RIMINI,ALLOY,T1.5,W4.5,L1.5mm,NTR,-,-
......3 BA68-03588A BIOS REV 1 LABEL-SPI RIMINI,SEC,paper,-,W4.5,L4mm,white,white,SPI,Revsion,-,-,-
......3 BA68-10191W SMT_SN 1 LABEL-BARCODE Note PC ALL,-,ARTPAPER,-,W6,L40mm,White,-,PCB-TOP/
BOTTOM,Barcode-SMT,-,-,-
......3 BA68-40012N MICOM_REV 1 LABEL-LOCATION NOTE PC,-,ART PAPER,-,W6.2,L6.2MM,-,-,-,-,-,-,-
......3 BA70-00606A EMI2 1 GASKET-EMI SANTAFE,BERYLLIUM COPPER,T0.08,BRIGHT TIN,W3.0,-
,L2.0*H4.0mm,HV370-HV410
......3 BA81-07945B SMT1 1 LEAD-1005 NP,SMT_SHORT,SOLDER-CREAM,0 OHM,-,-,-
......3
BA81-07945B SMT10 1 LEAD-1005 NP,SMT_SHORT,SOLDER-CREAM,0 OHM,-,-,-
......3 BA81-07945B SMT2 1 LEAD-1005 NP,SMT_SHORT,SOLDER-CREAM,0 OHM,-,-,-
......3 BA81-07945B SMT5 1 LEAD-1005 NP,SMT_SHORT,SOLDER-CREAM,0 OHM,-,-,-
......3 BA81-07945B SMT6 1 LEAD-1005 NP,SMT_SHORT,SOLDER-CREAM,0 OHM,-,-,-
......3 BA81-07945B SMT7 1 LEAD-1005 NP,SMT_SHORT,SOLDER-CREAM,0 OHM,-,-,-
......3 BA81-07945B SMT8 1 LEAD-1005 NP,SMT_SHORT,SOLDER-CREAM,0 OHM,-,-,-
......3 BA81-07945B SMT9 1 LEAD-1005 NP,SMT_SHORT,SOLDER-CREAM,0 OHM,-,-,-
......3 BA99-07565A SMT SUB MATERIAL 1 ASSY SUB/MATERIAL-
NP_SMT
N/P,SMT SUB/MATERIAL,RIBBON,SOLVENT,BOND,-
........4 0201-000160 PART ADHESIVE 0.001 ADHESIVE-TS D520,NTR
........4 0201-001002 ABLE BOND 0.001 ADHESIVE-TS 8380,SIL,9000CPS,10cc
........4 0202-001499 0.6 SMT 1 SOLDER-WIRE FLUX SR34 SUPER LFM-48,-,D0.6,96.5Sn/3Ag/0.5Cu,Flux_3.5%
........4 0202-001520 SOLDER CREAM 6 SOLDER-CREAM LFM-48X TM-HP,D25-45um,96.5Sn/3Ag/0.5Cu,Flux 12.0%
........4 0202-001704 SOLDER CREAM 6 SOLDER-CREAM NP303-CQS-2-F1,D22-32um,96.5Sn/3Ag/0.5Cu,Flux 11.5%
........4 0204-000199 METAL MASK SOLVENT 0.001 SOLVENT SUPANUKE-20,I.P.A,98%
....2 BA92-06119D SMT_D 1 ASSY MOTHER BD-
SMT_D
BREMEN-UL,PGA,DDR2,-,NT,-,SMT_D,PV/CONFIG1
......3 0401-000191 D1 1 DIODE-SWITCHING MMBD4148,100V,200mA,SOT-23,TP
......3 0401-000191 D13 1 DIODE-SWITCHING MMBD4148,100V,200mA,SOT-23,TP
......3 0404-001084 D14 1 DIODE-SCHOTTKY BAT54A,30V,200mA,SOT-23,TP
......3 0404-001084 D5 1 DIODE-SCHOTTKY BAT54A,30V,200mA,SOT-23,TP
......3 0404-001084 D7 1 DIODE-SCHOTTKY BAT54A,30V,200mA,SOT-23,TP
......3 0404-001382 D6 1 DIODE-SCHOTTKY CRS06,20V,1000mA,3-2A1A,TP
......3 0501-000465 Q9 1 TR-SMALL SIGNAL MMBT3904,NPN,350mW,SOT-23,TP,30-300
......3 0505-001007 Q20 1 FET-SILICON AO4822AL,N,30V,8.5A,0.016ohm,1.1W,SOIC-8
......3 0505-001007 Q25 1 FET-SILICON AO4822AL,N,30V,8.5A,0.016ohm,1.1W,SOIC-8
......3 0505-001007 Q7 1 FET-SILICON AO4822AL,N,30V,8.5A,0.016ohm,1.1W,SOIC-8
......3 0505-001064 Q22 1 FET-SILICON BSS138,N,50V,0.22A,3.5ohm,0.36W,SOT-23
......3 0505-001123 Q3 1 FET-SILICON SIR474DP,N,30V,20A,0.0075/0.0095ohm,29.8W,PowerPAK SO-8
......3 0505-001123 Q4 1 FET-SILICON SIR474DP,N,30V,20A,0.0075/0.0095ohm,29.8W,PowerPAK SO-8
......3 0505-001844 Q27 1 FET-SILICON SI4435DDY-T1-GE3,P,-30V,-11.4A,0.024ohm,5W,SO-8
......3 0505-001883 Q10 1 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323
......3 0505-001883 Q12 1 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323
......3 0505-001883 Q15 1 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323
......3 0505-001883 Q16 1 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323
......3 0505-001883 Q17 1 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323
......3 0505-001883 Q23 1 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323
......3 0505-001883 Q26 1 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323
......3 0505-001883 Q29 1 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323
......3 0505-001883 Q5 1 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323
