English 41
Installation
2. While pressing the hinge shaft down,
position the door so that the hinge shaft
is below the shaft hole in the middle
hinge. Release the hinge shaft so that it
enters the shaft hole.
3. With the door open, connect the bottom
connectors in the direction of the
arrows.
- This step only applies to the right
side freezer door (Cool Select+ door).
4. Attach the cover using a Phillips
screwdriver. Be careful not to damage or
step on the connectors.
- This step only applies to the right
side freezer door (Cool Select+ door).
5. Repeat steps 1-5 for the other door,
except for steps 3 and 4.
