6. Disassemble the Middle hinge.
7.RemovethefreezerdoorfromtheBottom
hinge by carefully lifting the door straight up.
The door is heavy, be careful not to
injure yourself when removing the door.
8. Lay the refrigerator carefully. Switch the
positionofBottomHingeandLeg.
9. Remove the screw on the bottom right side
of the fridge and freezer door. Switch Door
Stopper(
①
), Grommet(
②
)andBraket(
③
)from
the right to the left.
10. Switch the position of Gromet and Cap
screws.
Becarefulnottoinjureyourselfduring
operation.
11. Carefully put the freezer door back on.
Assemble the Middle hinge.
12.Use11mmwrenchtoseparatetheTophinge
shaft. Flip the Top hinge and reattach the Top
hinge shaft.
13. Carefully put the Fridge door back on and
assemble the hinge.
8_ Setting up
before
after
②
③
①
②
①
③
CAUTION
CAUTION
