Installation
English26
Installation
STEP 5 Adjust the door height
The height of a fridge door can be adjusted using the clamp nut and the height nut on the
front bottom of each door.
1. Open the door to adjust, and locate the
two nuts (A) and (B) on the front bottom
of the door.
2. With a 19 mm spanner, turn the clamp
nut (A) clockwise to loosen. Then, open
the door, and do the following inside the
door.
- To raise the door, turn the height nut
(B) counter clockwise.
- To lower the door, turn the height nut
(B) clockwise.
3. When complete, tighten the clamp nut
(A) by turning it counter clockwise.
