DISASSEMBLY & REASSEMBLY
- Need Tool
- DISASSEMBLY & REASSEMBLY
- All Series
IMAGE ITEM
Phillips Head
Driver
Head width less
than 3.5mm
Reference for previous Handle Type
ķ With flat screwdriver put into the Support
hole.
Rate screwdriver 90 degree, same time pull handle bar out.
ĸ
Just like last step to do for other parts,
loosed all parts and take out the handle.
H-TYPE HANDLE
T-TYPE HANDLE
ķ
ĸ
Ĺ
Ĺ
