English 45
Maintenance
STEP 6 Reverse the bottom hinge
1. Insert the door shaft into the bottom
hinge plate from the top as shown, and
then tighten it until it is securely in
place.
2. Insert the hinge bolt into the bottom
hinge plate from the top as shown, and
then tighten it until it is securely in
place.
3. Position the bottom hinge plate on the
opposite side, and then use two screws
to secure and attach the hinge plate as
shown.
