Samsung RT44A Series - Installation Clearance Requirements

Installation
English28
Installation
Clearance
See the pictures and table below for space requirements for installation.
B
C
A
Model RT44A* RT48A*
Depth "A"
720 mm 7
20 mm
Width “B” 700 mm 700 mm
Height “C” 1700 mm 1810 mm
03
01
03
05
02
04
RT44A* RT48A*
01
more than 50 mm recommended
02 115° (Freezer) / 120° (Fridge)
03 At least 50 mm
04
1056 mm 1056 mm
05 1383 mm 1383 mm
