Connecting and Using a Source Device
2
2 Connecting and Using a Source Device
Connection Using the DVI-HDMI Cable
Do not connect the power cable before connecting all other cables. Ensure you connect a source
device first before connecting the power cable.
1 Connect the DVI-HDMI cable to the [DVI IN] port on the back of the product and the HDMI port on
the PC.
2 Press [ ] to change the input source to DVI.
The [DVI IN] terminal is supplied for the DVI-dedicated models only.
Connection Using an DP Cable
Do not connect the power cable before connecting all other cables. Ensure you connect a source
device first before connecting the power cable.
1 Connect the DP cable to the [DP IN] port on the back of the product and the DP port on the PC.
2 Press [ ] to change the input source to DisplayPort.
The [DP IN] terminal is supplied for the DP-dedicated models only.
DVI IN
DVI IN
DP IN
DP IN
