S27CM80* / S32CM80* / S27C90*
1 2
3
Put the stand base onto the stand neck
as the direction shown in the figure.
Check that the stand neck is firmly
connected.
Tightly fasten the connecting screw at
the bottom of the stand base.
As shown in the figure, remove the
product and foam cushion, and then
place the product on the table with its
front side facing the floor.
4
5
Push the assembled stand into the main body in the direction of the arrow as
shown in the figure.
Stand assembly is complete.
