Samsung SCG14 - Page 2

a
d
e
g
f
b
c
y
x
w
v
h
t
u
k
f
i
j
nm op q
l
《Top side》
《Bottom side》
《Front side》
《Rear side》
s
r
a
Mouthpiece/Microphone (upper)
*1
b
Pen button
c
S Pen
d
Front camera
e
Proximity/Light sensor
*2
f
Edge screen
g
Display (Touch panel)
h
Receiver/Speaker
*1*3
i
Volume key
j
(Side key)
k
Fingerprint recognition sensor
l
Mouthpiece/Microphone (lower)
*1
m
S Pen slot
n
Speaker
*1
o
USB Type-C
®
connection terminal (external
connection terminal)
p
Tray eject hole
q
SIM card tray
r
5G/4G/GPS antenna part
*4
s
Rear camera
t
Wireless charging position
u
5G/4G antenna part
*4
v
Range AF sensor
w
Flash/Light
x
5G/4G/Wi-Fi
®
/Bluetooth
®
antenna part
*4
y
mark
*1 Be careful to not cover over with your ngers, etc.,
while relevant functions are being used. In addition, do
not insert the SIM card removal tool (sample) into the
product since this might cause damage.
*2 Do not cover with stickers, etc. Functions may not work
correctly.
*3 The product uses it for both a receiver and a speaker.
*4 The antenna is built into the main unit. Covering the
area around the antenna with your hand may a󰀨ect the
calling/communication quality.
