Samsung SP43R2HEX - 2. Alignment and Adjustments

Alignment and Adjustments
Samsung Electronics 2-1
2. Alignment and Adjustments
2-1 When entering the service mode;
1. Turn on the TV, and then select “STANDARD” on the picture adjustment mode.
2. Turn off the TV(STAND-BY).
3. Enter the service mode by pressing the remote control keys in the following sequence:
Info -> Menu -> Mute -> Power ON
Note : If necessary, re-do steps 1~3.
Initial display when the service mode is switched.
2-1-1 WHEN A RF SIGNAL IS RECEIVED
2-1-2 SERVICE MODE CONTROL KEYS
✍ PRECAUTIONS
1. When EEPROM IC (IC902) is replaced, first connect the power cord and wait for about 4~5 seconds.
2. After replacing EEPROM IC (IC902), enter the Service mode. Next, enter the standard data or the
previous EEPROM IC data before replacement. And then check and adjust any items related to
Geometric, Picture, Option.
DEFLECTION
DEFL. 480P OFFSET
DEFL. 1080I OFFSET
DEFL. 576P OFFSET
VIDEO ADJUST 1
VIDEO ADJUST 2
VIDEO ADJUST 3
VIDEO ADJUST 4
YC DELAY
VIDEO ADJUST DNIe 1
VIDEO ADJUST DNIe 2
OPTION F5 21 80
CHECKSUM 0000
RESET
T-CHMPEU-XXXX yy.mm.dd
MAIN MENU
UP / DOWN
RIGHT / LEFT
MENU DISPLAY
Select item by moving cursor
Decrease or increase the adjustment values
[Navigation Key]
