Samsung SP43R2HEX

To Next Page

To Previous Page

.....5 HC15 2402-001059 C-AL,SMD;220UF,20%,6.3V,-,TP,6X6.6X6.6

.....5 XC13 2402-001059 C-AL,SMD;220UF,20%,6.3V,-,TP,6X6.6X6.6

.....5 XC53 2402-001059 C-AL,SMD;220UF,20%,6.3V,-,TP,6X6.6X6.6

.....5 XC55 2402-001059 C-AL,SMD;220UF,20%,6.3V,-,TP,6X6.6X6.6

.....5 HC41 2402-001070 C-AL,SMD;470uF,20%,16V,GP,TP,10x10.2,-

.....5 XC15 2402-001070 C-AL,SMD;470uF,20%,16V,GP,TP,10x10.2,-

.....5 T0052 2703-000398 INDUCTOR-SMD;10uH,10%,3225

.....5 T0052 2703-001070 INDUCTOR-SMD;100uH,10%,4532

.....5 HX01 2801-001473 CRYSTAL-SMD;4MHz,50ppm,28-AAN,18pF,150oh

.....5 T0568 3301-001324 BEAD-SMD;15ohm,2012,600mA,TP,,,0.1ohm S.N.A

.....5 OO BP41-00143A PCB-DNLE;SP43W6,FR-4,4L,A,1.6T,100*95,J5 S.N.A

.....5 IC108 1002-001398 IC-A/D CONVERTER;MST9883CR-110,24Bit(8x3

.....5 HQ01 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2

.....5 Q409 0505-001905 FET-SILICON;2N7002,N,60V,115MA,7.5OHM,0.

.....5 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45§-,96.5Sn/ S.N.A

....4 CN902 3703-001175 CONNECTOR-BACK PANEL;64P,2R,MALE,ANGLE,A

....4 T0245 0202-001522 SOLDER-WIRE FLUX;LFA3-107,-,D1.2,96.5Sn/ S.N.A

...3 T0104 BP95-00132GASSY SUB PCB-MICOM;SP43W6HEX/XEH,P59A

....4 Q409 0505-000109 FET-SILICON;2N7000,N,60V,200mA,5ohm,400m

....4 X901 2801-004071 CRYSTAL-UNIT;6MHZ,30PPM,28-AAM,20PF,40OH

....4 CN902 3703-001175 CONNECTOR-BACK PANEL;64P,2R,MALE,ANGLE,A

....4 T0263 BP97-00618A ASSY SMD-MICOM;SP43W6HEX/XEH,P59A S.N.A

.....5 D900 0401-000133 DIODE-SWITCHING;RLS4148,75V,150MA,LL-34,

.....5 D901 0401-000133 DIODE-SWITCHING;RLS4148,75V,150MA,LL-34,

.....5 D903 0401-000133 DIODE-SWITCHING;RLS4148,75V,150MA,LL-34,

.....5 D904 0401-000133 DIODE-SWITCHING;RLS4148,75V,150MA,LL-34,

.....5 D905 0401-000133 DIODE-SWITCHING;RLS4148,75V,150MA,LL-34,

.....5 DZ900 0403-001375 DIODE-ZENER;RLZ3.6B,3.6-3.845V,500MW,LL-

.....5 DZ901 0403-001375 DIODE-ZENER;RLZ3.6B,3.6-3.845V,500MW,LL-

.....5 DZ902 0403-001375 DIODE-ZENER;RLZ3.6B,3.6-3.845V,500MW,LL-

.....5 DZ903 0403-001375 DIODE-ZENER;RLZ3.6B,3.6-3.845V,500MW,LL-

.....5 DZ905 0403-001375 DIODE-ZENER;RLZ3.6B,3.6-3.845V,500MW,LL-

.....5 DZ906 0403-001375 DIODE-ZENER;RLZ3.6B,3.6-3.845V,500MW,LL-

.....5 Q903 0501-000727 TR-SMALL SIGNAL;BC848C,NPN,310mW,SOT-23,

.....5 Q904 0501-000727 TR-SMALL SIGNAL;BC848C,NPN,310mW,SOT-23,

.....5 Q905 0501-000727 TR-SMALL SIGNAL;BC848C,NPN,310mW,SOT-23,

.....5 Q906 0501-000727 TR-SMALL SIGNAL;BC848C,NPN,310mW,SOT-23,

.....5 Q910 0501-000727 TR-SMALL SIGNAL;BC848C,NPN,310mW,SOT-23,

.....5 Q911 0501-000727 TR-SMALL SIGNAL;BC848C,NPN,310mW,SOT-23,

.....5 IC112 1103-001195 IC-EEPROM;24C64,8Kx8,SOP,P,5x4mm,2.7/5.5

.....5 IC113 1105-001305 IC-DRAM;4S641632,-,64MBIT,1MX16X4BIT,TSO

.....5 IC904 1203-001814 IC-VOL. DETECTOR;7025,SOT-89,4P,98MIL,PL

.....5 T0087 1203-002302 IC-POSI.FIXED REG.;78RM33D,D-PAK,3P,-,PL

.....5 T0087 1203-002351 IC-POSI.FIXED REG.;LF25C,DPAK,3P,240MIL,

.....5 IC901 1204-002105 IC-DECODER;SDA6001-B12,MQFP,128P,28x28mm

.....5 C949 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608

.....5 R888 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608

.....5 R896 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608

.....5 R939 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608

.....5 R948 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608

.....5 R969 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608

.....5 R910 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R911 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R921 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R922 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R923 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R924 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R926 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R928 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R929 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R944 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R945 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R946 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R947 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R949 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R955 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R956 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R962 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R963 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R977 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R981 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R985 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R986 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R992 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R994 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R996 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608

.....5 R925 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608

.....5 R897 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608

.....5 R907 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608

.....5 R908 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608

.....5 R927 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608

.....5 R957 2007-000081 R-CHIP;2.7Kohm,5%,1/10W,TP,1608

.....5 R958 2007-000081 R-CHIP;2.7Kohm,5%,1/10W,TP,1608

.....5 R999 2007-000081 R-CHIP;2.7Kohm,5%,1/10W,TP,1608

.....5 R903 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608

.....5 R895 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R905 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R906 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R913 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R917 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R918 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R932 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R933 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R934 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R970 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R971 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R972 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R973 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R974 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R975 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R976 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R978 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R979 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R982 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R991 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R993 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R998 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608

.....5 R894 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608

.....5 R909 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608

.....5 R914 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608

.....5 R915 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608

.....5 R916 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608

.....5 R930 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608

.....5 R936 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608

.....5 R942 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608

.....5 R943 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608

.....5 R961 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608

.....5 R987 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608

.....5 R988 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608

.....5 R995 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608

.....5 R953 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608

.....5 R954 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608

.....5 R904 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608

.....5 R931 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608

.....5 R901 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608

.....5 R902 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608

.....5 R935 2007-000493 R-CHIP;2.2Kohm,5%,1/8W,TP,2012

.....5 R951 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608

.....5 R997 2007-000857 R-CHIP;4.3Kohm,1%,1/10W,TP,1608

.....5 C950 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608

.....5 C901 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608

.....5 C902 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608

.....5 C908 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608

.....5 C918 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608

.....5 C921 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608

.....5 C922 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608

.....5 C923 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608

.....5 C925 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608

.....5 C926 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608

.....5 C927 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608

.....5 C928 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608

.....5 C929 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608

.....5 C930 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608

.....5 C931 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608

.....5 C932 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608

.....5 C947 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608

Electric Parts List

Samsung Electronics 4-3

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

Related product manuals

Samsung SP43R1HL1X/XEC

102 pages

Samsung SP43Q5HL

56 pages

Samsung SP43T8HPX/XEC

93 pages

Samsung SP42W4HPX/XEF

94 pages

Samsung SP47W3HFX/COM

118 pages

Samsung SP47Q5HL1X/XAX

Samsung PLH403W - PLH - 403W

60 pages

Samsung Projection Television

2 pages

Samsung SP43R2HEX - Page 60
