Installation
English30
Installation
Reattach the freezer doors
CAUTION
• Before reattaching the doors, make sure all the electrical connectors are properly
connected.
• The freezer door must be reattached before the fridge door.
• Be careful not to damage or step on the wires during this process.
1. Insert the freezer door into the bottom
hinge while pushing the freezer door in
the arrow direction.
CAUTION
• Be careful not to damage or step on the
wires during this process.
2. While pressing down the hinge shaft
of the door, reinsert the door into the
middle hinge.
3. With the door open, connect the bottom
connectors in the arrow directions.
