Samsung SyncMaster 2220LM - Preset Timing Modes

This monitor has a built-in power management system called PowerSaver. This system saves energy
by switching your monitor into a low-power mode when it has not been used for a certain amount of
time. The monitor automatically returns to normal operation when you press a key on the keyboard. For
energy conservation, turn your monitor OFF when it is not needed, or when leaving it unattended for
long periods. The PowerSaver system operates with a VESA DPM compliant video card installed in
your computer. Use a software utility installed on your computer to set up this feature.
State Normal Operation Power saving mode
Power off
(Power button OFF)
EPA/ENERGY 2000
Power Indicator Blue Blue blinking Off
Power Consumption Less than 55 watts
Less than
1 watts
Less than
1 watts
This monitor is EPA ENERGY STAR
®
compliant and ENERGY2000
compliant when used with a computer equipped with VESA DPM
functionality.
As an ENERGY STAR
®
Partner, SAMSUNG has determined that this
product meets the ENERGY STAR
®
guidelines for energy efficiency.
Preset Timing Modes
If the signal transferred from the computer is the same as the following Preset Timing Modes, the
screen will be adjusted automatically. However, if the signal differs, the screen may go blank while
the power LED is on. Refer to the video card manual and adjust the screen as follows.
Table 1. Preset Timing Modes
Display Mode
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Pixel Clock
(MHz)
Sync Polarity
(H/V)
IBM. 640 x 350 31.469 70.086 25.175 +/-
IBM. 640 x 480 31.469 59.940 25.175 -/-
IBM. 720 x 400 31.469 70.087 28.322 -/+
MAC. 640 x 480 35.000 66.667 30.240 -/-
MAC. 832 x 624 49.726 74.551 57.284 -/-
MAC. 1152 x 870 68.681 75.062 100.000 -/-
VESA. 640 x 480 31.469 59.940 25.175 -/-
VESA. 640 x 480 37.861 72.809 31.500 -/-
VESA. 640 x 480 37.500 75.000 31.500 -/-
