General
General
Model Name SyncMaster 710NT
LCD Panel
Size 17" Diagonal (43 cm)
Display area 337.92 mm (H) x 270.336 mm (V)
Pixel Pitch 0.264 mm (H) x 0.264 mm (V)
Type a-si TFT active matrix
Synchronization
Horizontal 30 ~ 81 kHz
Vertical 56 ~ 75 Hz
Display Color
16.2 M Colors
Resolution
Optimum resolution 1280 x 1024@60 Hz
Maximum resolution 1280 x 1024@75 Hz
Input Signal, Terminated
RGB Analog , 0,7 Vp-p Positive at 75 Ω
Separate H/V sync, TTL level positive or negative.
Maximum Pixel Clock
140 MHz
Power Supply
AC 100 to 240 VAC(+/- 10%), 60/50 Hz ± 3 Hz
Signal Cable
15pin to 15pin D-sub cable, Detachable
Power Consumption
Less than 45 W
