General
General
Model Name SyncMaster 913BM
LCD Panel
Size 19" Diagonal (48 cm)
Display area 376.32 mm (H) x 301.056 mm (V)
Pixel Pitch 0.294 mm (H) x 0.294 mm (V)
Synchronization
Horizontal 30 ~ 81 kHz
Vertical 56 ~ 75 Hz
Display Color
16.8M Colors
Resolution
Optimum resolution 1280 x 1024@60 Hz
Maximum resolution 1280 x 1024@75 Hz
Input Signal, Terminated
RGB Analog , DVI(Digital Visual Interface) Compliant Digital RGB
0.7Vp-p Positive at 75 Ω
Separate H/V sync, Composite sync, SOG, TTL level positive or negative.
Maximum Pixel Clock
140 MHz
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Signal Cable
15pin-to-15pin D-sub cable, detachable
DVI-D to DVI-D connector, detachable (not supplied)
Dimensions (WxHxD)/ Weight
416.6 X 377.5 X 64.2 mm / 16.4 X 14.9 X 2.5 inch (Without Stand)
416.6 X 420.6 X 200.0 mm / 16.4 X 16.6 X 7.9 inch (With Basic Stand) , 6.7 kg / 14.8 lbs
SyncMaster 913BM
