Model
General
General
Model Name SyncMaster 723N
LCD Panel
Size 17 inch (43 cm)
Display area 337.920 mm (H) x 270.336 mm (V)
Pixel Pitch 0.264 mm (H) x 0.264 mm (V)
Synchronization
Horizontal 30 ~ 81 k Hz
Vertical 56 ~ 75 Hz
Display Color
16.7M
Resolution
Optimum resolution 1280 x 1024@60 Hz
Maximum resolution 1280 x 1024@75 Hz
Input Signal, Terminated
RGB Analog
0.7 Vp-p ± 5 %
Separate H/V sync, Composite, SOG
TTL level (V high
≥
2.0 V, V low
≤
0.8 V)
Maximum Pixel Clock
135 MHz
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz
Signal Cable
15pin - to - 15pin D-sub cable, Detachable
SyncMaster 723N
