General
General
Model Name SyncMaster 960BF
LCD Panel
Size 19" Diagonal
Display area 376.32mm (H) x 301.056mm (V)
Pixel Pitch 0.294mm (H) x 0.294mm (V)
Type a-si TFT active matrix
Synchronization
Horizontal 30 ~ 81 kHz (Analog/Digital)
Vertical 56 ~ 75 Hz (Analog/Digital)
Display Color
16.7M Colors
Resolution
Optimum resolution 1280 x 1024@60 Hz
Maximum resolution 1280 x 1024@75 Hz
Input Signal, Terminated
RGB Analog, DVI(Digital Visual Interface) Compliant Digital RGB
0.7 Vp-p±5%, positive bright 75 Ω±10 % (terminated)
Separate H/V sync, Composite, SOG, TTL level, positive or negative
Maximum Pixel Clock
140 MHz (Analog/Digital)
Power Supply
AC 100 ~ 240 VAC ±10%, 60/50 Hz ± 3Hz
Signal Cable
DVI-A to D-Sub cable, Detachable, 1.8m
DVI-I to DVI-I connector, Detachable, 2.0m (Option)
Signal Connectors
