Samsung WF60F4E0W0W - Page 41

English - 41
08 APPENDIX
Sheet of household washing machines
The design and specifications are subject to change without notice for quality improvement purposes.
According to Regulation (EU) No. 1061/2010
" * " Asterisk(s) means variant model and can be varied (0-9) or (A-Z).
Samsung
Model Name
WF8*F5E*U4*
WF8*F5E*UH*
WF8*F5E*P4*
WF8*F5E*PH*
WF8*F5E*U2*
WF8*F5E*UM*
WF8*F5E*P2*
WF8*F5E*PM*
WF7*F5E*U4*
WF7*F5E*UH*
WF7*F5E*P4*
WF7*F5E*PH*
WF7*F5E*U2*
WF7*F5E*UM*
WF7*F5E*P2*
WF7*F5E*PM*
Capacity kg 8.0 7.0
Energy Eciency
A + + + (highest efficiency) to D (least efficient) A+++ A+++
Energy Consumption
Annual Energy Consumption (AE_C)
1)
kWh/yr 157 122
Energy consumption (E_t.60) Cotton 60 ˚C at full load kWh 0.88 0.68
Energy consumption (E_t.60.1/2) Cotton 60 ˚C with
partial load
kWh 0.68 0.52
Energy consumption (E_t.40.1/2) Cotton 40 ˚C with
partial load
kWh 0.41 0.34
Weighted power off-mode (P_o) W 0.48 0.48
Weighted Power in left-on mode (P_l) W 5.00 5.00
Annual water consumption (AW_c)
2)
L/yr 10500 9400
Spin eciency class
3)
A (most efficient) to G (least efficient) B B
Maximum Spin Speed rpm 1400 1200 1400 1200
Residual moisture % 53 56 53 56
Programs to which the information on the label and the Sheet relate Cotton 60 ˚C and 40 ˚C + Intensive
4)
Program duration of the standard program
Cotton 60 ˚C at full load min 242 242
Cotton 60 ˚C for partial load min 194 214
Cotton 40 ˚C with partial load min 174 174
Weighted time in left-on mode min 2 2
Airborne noise emissions
Wash dB (A) re 1 pW 53 54
Spin dB (A) re 1 pW 74 74
Dimensions
Unit dimensions
Height mm 850 850
Width mm 600 600
Depth
5)
mm 550 550
Net weight kg 61 61
Gross weight kg 63 63
Package weight kg 2 2
Water Pressure kPa 50–800 50–800
Electrical connection
Voltage V 220–240 220–240
Power consumption W 2000–2400 2000–2400
Frequency Hz 50 50
Name of company Samsung Electronics Co., Ltd.
