3
TV SIZE TV LOAD
VESA COMPLIANCE SWIVEL
32” - 60” 27 kg
100 x 100 mm – 600 x 400 mm
Safety Warnings
WARNING! READ THE FOLLOWING BEFORE STARTING INSTALLATION
• It is the installers’ responsibility to verify that the wall will safely support the total load of the TV and the TV bracket.
Never exceed the designated maximum TV load.
• Assembly is required. Installation must be carried out by qualied personnel only. Incorrect assembly can result in
severe personal injury and property damage.
• The supplied safety strap is suitable for use on vertical walls constructed from solid brick, solid concrete, solid wood
and solid wooden columns.
• Parts are heavy; take care when handling. For some steps, 2 people are required for installation.
• Check the TV bracket frequently to ensure that it is safe and secure. Additional tools (not included) are required for the
installation. Do not over-tighten screws.
• Use of the safety strap prevents the TV from falling.
• Keep children away from the mounted safety strap.
• Keep this instruction manual for future reference.
Tooling
