8
A14
A9
A15
Ø7 mm
40 mm
Ø3.5 mm
40 mm
A14
A9
7
6
Ensure mounting screws are in the
centre of the timber stud.
• The safety strap must be used to
prevent the product from falling.
• To prevent falling backwards, it
is recommended to place the
product near the wall.
