For TVs with a ๎ at/unobstructed back. Ensure
that the bracket is level on the back of the TV.
Standard con๎ gurations are shown. If you need
extra space to accommodate cables, recesses,
or protrusions, see installation option 1-2, 1-3,
or 1-4 that uses spacers. For special
applications, or if you
are uncertain about
your hardware
selection, contact
Customer Service.
6901-002051 <05>
9
1-1
