SANY SCC3000US - Page 20

40.5 43.5 46.5
(ft)
(132′10″) (142′9″) (152′7″)
8.0 8.7/120
(26′3″) (28′7″/264)
9.0 118.0 9.2/108.3 9.8/99
(29′6″) (260.1) (30′2″/238) (32′2″/218)
10.0 107.7 104.3 97.3 10.3/93 10.3/93 10.8/85.1 10.8/85.1
(32′10″) (237.4) (229.9) (214.5) (33′10″/205) (33′10″/205) (35′5″/187) (35′5″/187)
12.0 86.0 85.6 84.6 82.5 82.5 79.7 79.7
(39′4″) (189.5) (188.7) (186.5) (181.8) (181.8) (175.7) (175.7)
14.0 75.0 74.8 65.7 64.3 70.3 68.3 68.3
(45′11″) (165.3) (164.9) (144.8) (141.7) (154.9) (150.5) (150.5)
16.0 62.2 61.9 61.0 60.2 61.4 59.5 60.7
(52′6″) (137.1) (136.4) (134.4) (132.7) (135.3) (131.1) (133.8)
18.0 53.1
52.9 52.3 51.8 52.8 51.1 52.2
(59′1″) (117) (116.6) (115.3) (114.1) (116.4) (112.6) (115)
20.0 45.9 45.7 45.5 45.2 46.1 44.6 45.6
(65′7″) (101.1) (100.7) (100.3) (99.6) (101.6) (98.3) (100.5)
22.0 40.3 40.1 39.8 39.6 40.4 39.4 40.2
(72′2″) (88.8) (88.4) (87.7) (87.3) (89) (86.8) (88.6)
24.0 35.7 35.5 35.2 35.1 35.8 34.8 35.5
(78′9″) (78.7) (78.2) (77.6) (77.3) (78.9) (76.7) (78.2)
26.0 31.9 31.7 31.5 31.3 32.0 31.0 31.7
(85′4″) (70.3) (69.8) (69.4) (69) (70.5) (68.3) (69.8)
28.0 28.8 28.6 28.3 28.1 28.7 27.9 28.5
(91′10″) (63.4) (63) (62.3) (61.9) (63.2) (61.5) (62.8)
30.0 26.1 25.9 25.6 25.4 26.0 25.2 25.8
(98′5″) (57.5) (57) (56.4) (55.9) (57.3) (55.5) (56.8)
32.0 23.8 23.5 23.3 23.1 23.7 22.9 23.4
(104′12″) (52.4) (51.8) (51.3) (50.9) (52.2) (50.4) (51.5)
34.0 21.8 21.5 21.3 21.1 21.6 20.8 21.3
(111′7″) (48)
(47.3) (46.9) (46.5) (47.6) (45.8) (46.9)
36.0 20.1 19.8 19.6 19.4 19.8 19.1 19.6
(118′1″) (44.3) (43.6) (43.2) (42.7) (43.6) (42.1) (43.2)
38.0 36.7/18.9 18.3 18.0 17.8 18.3 17.5 18.0
(124′8″) (120′5″/41) (40.3) (39.6) (39.2) (40.3) (38.5) (39.6)
40.0 39.3/16.8 16.6 16.4 16.8 16.1 16.6
(131′3″) (128′11″/37) (36.5) (36.1) (37) (35.4) (36.5)
42.0 41.9/15 15.2 15.6 14.9 15.3
(137′10″) (137′6″/33) (33.5) (34.3) (32.8) (33.7)
44.0 14.1 14.5 13.8 14.1
(144′4″) (31) (31.9) (30.4) (31)
46.0 44.5/13.2 44.5/14.1 12.8 13.1
(150′11″) (145′12″/29) (145′12″/31) (28.2) (28.8)
48.0 47.1/11.2 47.1/12
(157′6″) (154′6″/24) (154′6″/26)
50.0
(164′0″)
Counter- 85.2
85.2 85.2 85.2 85.2+5.8 85.2 85.2+5.8
weight (187.8) (187.8) (187.8) (187.8) (187.8＋12.7) (187.8) (187.8＋12.7)
(162′5″) (172′3″)
52.549.5
Radius（m）
Length of Main Boom（m） (ft)
Load Charts of Boom Hook For SCC3000US HC Operating Condition
(including extension Jib and ball hook) Unit：Kg(lb)×1000
4.2: 2/6
