SANY SCC3000US - Load Charts of Extension Jib Hook for LJ Operating Condition

- 15 / 16 -
SCC3000US Crawler Crane ― Operation Manual
Section 4-Load Charts
4.7Load Charts of Jib Hook for LJ Operating Condition
Combination of Lufng Jib
Load Charts of Jib Hook for LJ Operating condition
Combination of Luffing Jib
Jib Insert
Jib Length
（m）
3 m(9'10") 6 m(19'8") 12m(39'4")
Boom Length (m)
Boom
Angle
22(72'2") 1 1
－ 22.5～58.5(73'10"～191'11") 63°～88°
25(82')
－ －
1
22.5～61.5(73'10"～201'9") 63°～88°
31(101'8")
－
1 1
22.5～61.5(73'10"～201'9") 63°～88°
37(121'5")
－ －
2
22.5～61.5(73'10"～201'9") 63°～88°
43(141'1")
－
1 2
22.5～61.5(73'10"～201'9") 63°
～88°
52(170'7") 1
－
3
22.5～61.5(73'10"～201'9") 63°～88°
61(200 2 ) 2 1 3
22.5～52.522.5～52.5(73'10"～172'3") 63°～88°
Jib Hook
Jib tip(6.5m)
(21'4")
12m(39'4") Jib insert
(21'4'')
6m(19'8") Jib insert
3m (9'10")Jib insert
Jib base(6.5m)
Main boom(22.5m-61.5m)
(73'10''-201'9"m)
LJ Operating Conditon
(3 sections)
(1 section)
(2 section)
Jib Length (m)(ft)
Jib Insert (m)(ft)
Boom Length (m)(ft)
Boom
Angle
3(9'10") 6(19'8") 12(39'4")
22(72'2") 1 1
－
22.5
～
58.5(73’10”
～
191’11”) 63°
～
88°
25(82')
－ －
1 22.5
～
61.5(73’10”
～
201’9”) 63°
～
88°
31(101'8")
－
1 1 22.5
～
61.5(73’10”
～
201’9”) 63°
～
88°
37(121'5")
－ －
2 22.5
～
61.5(73’10”
～
201’9”) 63°
～
88°
43(141'1")
－
1 2 22.5
～
61.5(73’10”
～
201’9”) 63°
～
88°
52(170'7") 1
－
3 22.5
～
61.5(73’10”
～
201’9”) 63°
～
88°
61(200′2″) 2 1 3 22.5
～
52.5(73’10”
～
172’3”) 63°
～
88°
LJ Operating Condition
Notes: Figures in framed cells indicate that
the rated load depends on the strength.
Notice:
1. The actual hoisting capacity shall be the
value of rated hoisting capacity deducting
the weight of hook blocks, wire ropes and
all the spreaders.
2. The rated load shown in the table is the
weight of cargo which is slowly and steadily
lifted by crane on flat and hard ground
under the non-travel load condition.
3. The load rating is calculated not exceed
75percent of the load depending on stability
or structure.
