Sanyo DS25204 User Manual

404 081 2807 MT-POLYPRO 0.33U J 250V 403 349 3204 MT-POLYPRO 0.30U J 250V
★ C416 403 346 7205 MT-POLYPRO 0.33U J 250V 403 372 6906 MT-POLYPRO 0.30U J 250V
403 372 7002 MT-POLYPRO 0.33U J 250V 403 392 8607 MT-POLYPRO 0.30U J 250V
D834
408 047 4706 ZENER DIODE MTZJ15B (15V) 408 047 8308 ZENER DIODE MTZJ6.2C (6.2V)
408 047 5000 ZENER DIODE MTZJ15C (15V) N/A NOT USED
★ L902 610 003 4846 DEFLECTION YOKE 645 076 4455 DEFLECTION YOKE
★ R407A 401 063 5306 OXIDE-MT 82 JA 1W 401 059 6706 OXIDE-MT 180 JA 1W
★ R421 401 286 5305 MT-FILM 2.4K FA 1/6W 401 086 5802 MT-FILM 2.7K FA 1/6W
R493 401 012 8105 CARBON 100K JA 1/4W 401 015 4708 CARBON 180K JA 1/4W
R494 401 012 8105 CARBON 100K JA 1/4W 401 015 4708 CARBON 180K JA 1/4W
★ R497 401 066 3002 OXIDE-MT 2.2 JA 2W 401 067 3100 OXIDE-MT 3.9 JA 2W
★ T402 645 058 0529 TRANS, FLYBACK 652 001 1212 TRANS, FLYBACK
A100 610 304 9670 ASSY, PWB, MAIN 610 320 0484 ASSY, PWB, MAIN
645 052 6077 TUNER, U/V 645 063 9814 TUNER, U/V
★ A101
645 052 6091 TUNER, U/V 645 063 9821 TUNER, U/V
A700 610 304 9687 ASSY, PWB, CRT 610 320 0491 ASSY, PWB, CRT
★ K701 645 028 0306 SOCKET, CRT, 8P 652 001 1472 SOCKET, CRT, 8P
★ Q901 414 009 1300 CRT A63AHC26X 414 013 3505 CRT A60QFU891X
2. IN THE CHASSIS ELECTRICAL PARTS LIST
MODEL DS25320 (Chassis No. 25320-06)
MODEL DS24205 (Chassis No. 24205-00)
Part No. Description
KEY NO.
Part No. Description
– 3 –
