Table 1. ON-SCREEN SERVICE MENU
When IC802 (EEPROM) is replaced, check the bus data to confirm they are the same as below. The shaded menu should be
checked and be set up or readjusted according to the procedures described in the following pages. Initial Setup Data marked
with an * should be changed from Initial Reference Data. (See page 3 for Initial Bus Data Setup.)
No. TITLE
INITIAL REFERENCE INITIAL SETUP INITIAL SETUP
FUNCTION
DATA HEX DATA HEX DATA BINARY
3C SCO 0A ID* 00011101 Sub Color
3D STI 05 07* 00000111 Sub Tint
3E SB 20 20 00100000 Sub Bright
3F SSH 12 05* 00000101 Sub Sharpness
40 AFC6HFR 9E 9E 10011110 AFC / Horizontal Frequency
41 HBS7HP 0F 0F 00001111 Horizontal Blanking / Horizontal Phase
42 VS 32 49* 01001001 Vertical Size
43 VSP7VPO 05 05 00000101 Vertical Sync Separator / Vertical Position
44 GRY7CRS5VLN 8E 90* 10010000 Gray Mode / Cross Black/White / Vertical Linearity
45 HBL5VSC EC EE* 11101110 Horizontal Blanking Right / Vertical S Correction
46 VC3CDM 28 28 00101000 Vertical Compression / Vertical Count Down
47 RB 00 00 00000000 Red Bias
48 GB 00 00 00000000 Green Bias
49 BB 00 00 00000000 Blue Bias
4A RD 40 40 01000000 Red Drive
4B BGS5RGD4GD 08 0B* 00001011 Blue Gamma / Red-Green Gamma / Green Drive Reduction
4C BD 40 40 01000000 Blue Drive
4D SBI 20 38* 00111000 Sub Bias
4E ↓↓↓↓Not Used
4F ↓↓↓↓Not Used
50 OSD 01 01 00000001 On Screen Display Contrast
51 BSD7CR6 40 40 01000000 Black Stretch / Coring
52 ↓↓↓↓Not Used
53 ↓↓↓↓Not Used
54 FLS 01 01 00000001 Y/C Filter Mode
55 GYA3CKO 02 02 00000010 G-Y Angle / Color Killer Operation
56 FBP6WP4PRE2CRG 4A 4A 01001010 FBP Blanking / W Peak Limit / Preshoot Adj / Coring Gain
57 DCR4BSS2BSG 08 02* 00000010 DC Reset / Black Stretch Start / Black Stretch Gain
58 AFC7CBP5 00 80* 10000000 Auto Flesh / Color Band Pass Filter
59 DIG6ABL5MSD4BAT 04 04 00000100 OSD D/A / ABL Defeat / Mid Stop / ABL Threshold
5A RYA 02 02 00000010 R-Y/B-Y Angle
5B ↓↓↓↓Not Used
5C ↓↓↓↓Not Used
5D RAD 0F 0F 00001111 RF AGC Delay
5E FMM7IAS 00 00 00000000 FM Mute / IF AGC
5F VL5FL 67 67 01100111 Video Level / FM Level
60 HBL5 E0 00* 00000000 Horizontal Blanking Left
83 OPT 04 84* 10000100 AV Option (See Note 3)
84 OP2 00 00 00000000 Game / V-Guide Option (See Note 4)
8D HR 13 13 00010011 Horizontal Display Position
8E SBO 03 02* 00000010 Sub Bright Offset
8F DRV
R40 R40 01000000 Red Drive Adjustment (See Note 1.)
B40 B40 01000000 Blue Drive Adjustment (See Note 1.)
– - - - Red Bias Adjustment (See Note 2.)
90 – - - - Green Bias Adjustment (See Note 2.)
– - - Blue Bias Adjustment (See Note 2.)
B0 ↓↓↓↓Not Used
↓↓ ↓ ↓ ↓↓
F8 ↓↓↓↓Not Used
