Table 1. ON-SCREEN SERVICE MENU
When IC802 (EEPROM) is replaced, check the bus data to confirm they are the same as below. The shaded menu should be
checked and be set up or readjusted according to the procedures described in the following pages. Initial Setup Data marked
with an * should be changed from Initial Reference Data. (See pages 3 and 4 for Initial Bus Data Setup.)
NO. TITLE
INITIAL REFERENCE INITIAL SETUP
RANGE OF DATA FUNCTION
DATA DATA
01 HFR 7 7 0~63 Horizontal Frequency
02 C16 244 244 0~255 16:9 Mode Contrast Offset
03 VPO 0 0 0~63 Vertical Position
04 VS 29 17* 0~63 Vertical Size
05 VLN 6 8* 0~15 Vertical Linearity
06 VSC 0 2* 0~15 Vertical S Correction
07 HP 20 24* 0~63 Horizontal Position
08 EWD 29 34* 0~63 Horizontal Width
09 EWA 43 35* 0~63 Pin Amp
10 EWP 29 34* 0~63 Up Corner Pin
11 EWB 37 37 0~63 Bottom Corner Pin
12 BOW 10 7* 0~15 AFC Bow
13 ANG 9 8* 0~15 AFC Angle
14 UVL 2 0* 0~15 Upper Vertical Linearity
15 LVL 1 0* 0~15 Lower Vertical Linearity
16 EWT 8 4* 0~15 Pin Phase
17 VC 6 5* 0~15 Vertical Compression
18 RD 31 31 0~63 Red Drive
19 GD 31 31 0~63 Green Drive
20 BD 31 31 0~63 Blue Drive
21 RB 13 6* 0~15 Red Cutoff
22 GB 2 0* 0~15 Green Cutoff
23 BB 8 0* 0~15 Blue Cutoff
24 FLS 3 3 0~3 Filter System
25 SCN 11 11 0~15 Sub Contrast
26 STI 7 15* 0~15 Sub Tint
27 SCO 7 9* 0~15 Sub Color
28 SB 7 12* 0~31 Sub Bright
29 SSH 0 2* 0~255 Sub Sharpness
30 AFC 0 0 0~3 AFC Gain (Except TV Mode)
31 REF 0 0 0, 1 Reference Pulse Position
32 CDM 3 3 0~3 CD Mode Select
33 DCO 1 0* 0, 1 Dynamic Color Switch
34 ABL 1 1 0, 1 ABL Mode Switch
35 BAT 1 1 0, 1 ABL Level Switch 4:3 Mode
36 B16 1 1 0, 1 ABL Level Switch 16:9 Mode
37 CTP 1 1 0, 1 Chroma Trap Off Switch
38 CBP 0 0 0, 7 Chroma Bandpass Filter Switch
39 DCR 2 3* 0~3 DC Transmission select Switch
40 YGM 1 2* 0~3 Gamma Correction Select
41 POS 1 1 0, 1 Preshoot/Overshoot Switch
42 WP 0 0 0~3 RGB Limit Level
43 VM 3 3 0~3 Velocity Modulation
44 GYA 0 0 0, 1 G-Y Angle
45 CRS 0 0 0, 1 Aging Mode
46 HMA 1 1 0, 1 H Mask On/Off
47 HBS 1 1 0, 1 Horizontal Blanking Switch
To Next Page
