Sanyo PLV-Z5 - Polarized Glasses Removal.

- 35 -
23
Polarized glasses removal.
1.Remove the screw-A(M2x5) and remove the Polarized glass ass'y (IN-G).
2.Remove the screw-B(M2x5) and remove the Polarized glass ass'y (IN-B).
A
B
Fig. 23-a
Polarized glass ass'y(IN-G)
Polarized glass ass'y(IN-B)
Fig. 23-b
Polarized Glass ass'y (IN-G)
Holder
Polarized Glass(IN-G)
Stopper
Push the Polarized glass upward, unhook the holder and
remove the Polarized glass.
Hook
Optical disassemblies
