1.5 FUSE / MCB TABLE
Fuse Rating Fuse Colour Wire Colour Description
1 10 Amps Red Slate Front roof lights
2 10 Amps Red Pink Rear roof lights
3 5 Amps Tan Yellow / Green Water Heater Ignition (if fitted)
4 10 Amps Red Purple Water pump / Toilet pump
5 10 Amps Red Yellow / White 12v Sockets
6 15 Amps Blue Red Fridge
7 20 Amps Yellow Green Supply from Car
8 15 Amps Blue * Charger (internally connected)
Battery 20 Amps Yellow Brown / Blue Fuse remotely located near battery
MCB Rating Wire Colour Description
1 10 Amps White 240v Sockets
2 10 Amps White 240v Sockets / Fridge
3 6 Amps Orange - Lights / Blue - Heater Lights / Water Heater / 12v Charger
