Satec Expertmeter Series Reference Guide

29
3.3 Device Control and Status Registers
Point ID
Description
Options/Range
Units
Type
R
/
W
Notes
Device Reset/Clear Registers
0xA000
Clear total energy registers
0
UINT
16
R/
W
Read as 0
0xA001
Clear total maximum demand registers
0 = Clear all maximum
demands
1 = Clear power demands
2 = Clear volt and ampere
demands
UINT
16
R/
W
0xA004
Clear pulse counters
0 = Clear all counters
1-4 = Clear counter #1-#4
UINT
16
R/
W
0xA005
Clear Min/Max log
0
UINT
16
R/
W
Device Status Registers
0x7D03
Present setpoint status SP1-SP16
0x0000-0xFFFF
UINT
16
R
Bitmap: 0=released, 1=operated
0x7D06
Current serial port number
1=COM2
UINT
16
R
Alarm Notification Registers
0x7E00
Latched setpoint SP1-SP16 alarm status.
Nonvolatile register.
0x0000-0xFFFF
UINT
16
R/
W
Bitmap:
read: 1=setpoint has been operated at
least once since last reset;
write: 0=clear alarm, 1=has no effect
0x7E01
Device diagnostics. Nonvolatile register.
F23
UINT
16
R/
W
Bitmap:
read: 1=diagnostic failed at least once
since last reset;
write: 0=clear diagnostic flag, 1=has no
effect
Device Identification
0x7F00-
0x7F01
Device options
F28
UINT
16
R
