Satec Expertmeter Series Reference Guide

31
Address
Description
Options/Range
Units
Type
R
/
W
Notes
0x81F3
Current scale, in secondary amps = CT secondary
current (1A, 5A)  Current overload
20, 100 (2.0A, 10.0A)
0.1A
UINT
16
R
Communication Ports Setup
0x8500-
0x851F
+0
Communication protocol
COM1: 0=SATEC ASCII,
1=Modbus RTU, 2=DNP3.0, 7=
IEC 60870-5
COM2: 8=CANopen
UINT
16
R
+1
Interface
COM1: 2=RS-485
COM2: 10=CANopen
UINT
16
R
+2
Device address
SATEC ASCII: 0-99
Modbus RTU: 1-247
DNP3.0: 0-65532
CANopen: 0-126
UINT
16
R
+3
Baud rate
COM1: 1=300 bps, 2=600 bps,
3=1200 bps, 4=2400 bps,
5=4800 bps, 6=9600 bps,
7=19200 bps, 8=38400 bps,
9=57600 bps, 10=115200 bps
COM2: 9=57600 bps
UINT
16
R
COM2 baud rate does not concern the
CANopen baud rate
+4
Data format
COM1: 0=7 bits/even parity,
1=8 bits/no parity,
2=8 bits/even parity
COM2: 1=8 bits/no parity
UINT
16
R
+5
Flow control
N/A
UINT
16
R
Read as 65535
+6
RTS mode
N/A
UINT
16
R
Read as 65535
+7
Send delay
2-1000 ms
UINT
16
R
+8-15
Reserved
UINT
16
R
0x8500-
0x850F
COM1 Setup
0x8510-
0x851F
COM2 Setup
Basic Setup
0x8600-
0x8614
+0
Wiring mode
F2
UINT
16
R/
W
