Fig. 3. Alignment of the indicators when closing the detector housing.
4. Technical data
Nominal supply voltage (±15%).......................................................................... 12V DC
Mean current consumption (±10%): DG-1 CO..........................................................12mA
DG-1 LPG........................................................35mA
DG-1 ME..........................................................35mA
DG-1 TCM .......................................................80mA
Operating temperature range ........................................................................-10...+55°C
Dimensions ................................................................................................... ø97x36mm
The latest EC declaration of conformity and product approval certificates
are available for downloading on website www.satel.pl
SATEL sp. z o.o.
ul. Schuberta 79
80-172 Gdańsk
POLAND
tel. + 48 58 320 94 00
info@satel.pl
www.satel.pl
