Fasten the METAL BRACKETS (19G) to the UPPER
BACK MOLDING (MM). Use two BLACK 9/16" LARGE
HEAD SCREWS (1S).
å
Fasten the UPPER BACK MOLDING (MM) to the TOP
REAR MOLDING (LL) on the TOP (F2). Tighten three
TWIST-LOCK® FASTENERS.
Step 8
416513www.sauder.com/services
Page 15
LL
F2
MM
How to use the SAUDER TWIST-LOCK
®
FASTENER
1. Insert the dowel end of the FASTENER into the
hole of the adjoining part.
NOTE: The dowel end of the FASTENER must
remain fully inserted in the hole of the adjoining
part while locking the FASTENER.
2. Tighten the FASTENER with a Phillips
screwdriver as tight as possible.
Edge and surface with
TWIST-LOCK® FASTENERS
MM
Dowel end
BLACK 9/16" LARGE HEAD SCREW
(2 used in this step)
1S
19G
19G
