Sauder Avenue Eight 416513 - Page 20

Step 13
å
Fasten the BOTTOMS (G2) to the OUTER ENDS (A). Tighten
four TWIST-LOCK® FASTENERS.
å
Fasten the BOTTOMS (G2) to the ENDS (B3 and C3). Use
four BLACK 1-15/16" FLAT HEAD SCREWS (113S).
å
Insert four METAL PINS (1R) into the PEDESTAL BACK (J).
å
Insert the METAL PINS (1R) in one end of the PEDESTAL
BACK (J) into the holes in the LEFT END (C3).
416513 www.sauder.com/servicesPage 20
Surface with
TWIST-LOCK
®
FASTENERS
Surface with
TWIST-LOCK
®
FASTENERS
A
A
J
C3
G2
G2
B3
The large holes must be here.
Unfi nished
surface
(4 used)
1R
113S
BLACK 1-15/16" FLAT HEAD SCREW
(4 used in this step)
113S
