SAXON TRAVELLER SCOPE INSTRUCTION MANUAL 2 | P a g e
CAUTION!
Never use your telescope to look directly at the sun. Permanent eye damage will
result. Use a proper solar filter for viewing the sun. When observing the sun, place a
dust cap over your finderscope to protect it from exposure. Never use an eyepiece-
type solar filter and never use your telescope to project sunlight onto another
surface, the internal heat build-up will damage the telescope optical elements.
Tripod Head Platform
Alt-Azimuth Knob/
Adjustment
Central Column
Locking Knob
Finderscope
Eyepiece
Focuser Knob
Telescope Optical Tube
Pan Handle/
Altitude Adjustment
Tripod Leg Lock Clamps
for height adjustment
Erect Prism Diagonal
Central Column
Tripod Leg
Scope Locking Knob
Saxon Traveller Scope Features
