Scale-Tronix 6202 - Page 3

PATIENT WEIGHING SYSTEMS
TABLE OF CONTENTS PAGE
1 GENERAL DESCRIPTION 1
И ASSEMBLY - SET UP 5
山 OPERATION OF SCALES 9
м TECHNICAL DESCRIPTION 17
V PARTS LIST AND SCHEMATIC 33
VI WARRANTY 45
This User's manual is intended to provide ali necessary information and data for the proper operation and service of
the SECOND GENERATION PATIENT WEIGHING SYSTEMS manufactured by SCALE-TRONIX®, INC, This
manual should be studied before installing or placing the scale in service. Please store in a safe, handy place for
future reference. Additional manuals are available from SCALE-TRONIX®, INC. at a nominal charge. Refer to the
scale serial and model numbers in any and all correspondence.
Feel free to call the factory for service and operational assistance - 630-653-3377.
