display.
4.25.2
NON-VOLATILE
MEMORY
The
internal
memory
of
microcomputer
U10
does
not
retain
data
when
the
power
is
switched
off.
Because
some
features
of
the
scale
may
require
lasting
data
retention
(such
as
last
weight
recall)
integrated
circuit
U
is
included.
This
device,
called
an
"electrically
erasable
programmable
tead
only
memory",
or
"EEPROM"
will
store
selected
information
for
periods
of
up
to
100
years.
Information
needed
to
be
stored
to
or
retrieved
from
U
is
sent
in
serial
form
using
the
lines
SCL
(serial
clock)
and
SDA
(serial
data).
These
are
controlled
by
microcomputer
U10.
A
data
bit
(a
high
or
low
level)
is
sent
and
received
on
SDA
when
the
SCL.
line
provides
a
pulse.
Resistors
R54/R55
are
provided
as
pull-ups
on the
SCL/SDA
lines
to
insure
the
data
and
clock
pulses
are
properly
shaped.
Capacitor
C36
improves
power
supply
bypassing.
4.25.3
RESET
GENERATION
In
order
for
microcomputer
16
to
properly
execute
its
software
instructions
it
must
be
initialized
to
the
start
of
the
program
when
power
is
first
turned
on,
Reset
pin
9
of
U10
will
accomplish
this
when
it
is
set
"high".
23005
R01
board:
RC
network
C31/R40
is
provided
to
generate
a
momentary
pulse
on
power
up
which
is
coupled
to
the
/RS
pin
of
U10.
No
reset
of
port
expander
integrated
circuit
U7
is
provided.
U7's
reset
pin
is
permanently
connected
to
ground
through
resistor
R39.
23005
ROZ
board:
A
reset
pulse
of
approximately
200
mS
is
automatically
generated
by
“watchdog
timer”
U11
when
the
Vcc
level
rises
above
4.65
volts.
Усс
is
below
4,65
volts
the
reset
line
stays
"high",
keeping
the
microcomputer
U10
in
an
inactive
state.
The
reset
puise
is
also
connected
to
port
expander
U7.
“The
model
5102
also
contains
a
jumper
on
J7 that
causes
watchdog
timer
U11
to
generate
a
reset
pulse
to
U10
in
the
event
of
a
watchdog
timeout due
to
hardware
or
software
failure.
4.30
DISPLAY
BOARD
Presentation
of
the
weight
information
is
performed
by
the
model
22DSDP
display
board.
it
incorporates
LED
(light-emitting
diode)
digits
and
annunciators
to
provide
a
clear,
bright,
easy-to-read
display.
The
weight
value
is
displayed
on
six,
0.43”
high
common
cathode
digits.
These
are
driven
in
a
multiplexed
fashion
(one
digit
on
at
a
time)
by
LED
driver
UT.
U1
receives
the
digit
display
information
from
the
microcomputer's
parallel
data
bus
(DB0-DB7)
and
automatically
performs
the
multiplexing
function.
Resistor
package
RP1
sets
the
operating
current
level
for
the
displays.
A
variety
of
LED
annunciator
lamps
are
contained
on
the
front
panel
to
indicate
"POUNDS"
or
“KILOGRAMS”,
"PRIOR
WEIGHT",
and
"LO
BATT".
These
annunciator lamps
contain
multiple
LED's
to
provide
an
evenly
illuminated
surface.
They
are
driven
by
integrated
circuit
U2.
U2 receives
the
on/off
information
for
the
annunciators
from
microcomputer
U10
via
port
expander
circuit
U7.
Resistor
packs
RP2
and
RP3
provide
current
limiting
for
the
annunciators.
Display
boards
22DSP
R01,
22DSP
R02,
and
22DSP
R03
are
all
equivalent
in
operation
with
some
minor
changes
in
board
layout
to
improve
spacings.
Seme
minor differences
in
connections
to
the
terminals
of
the
resistor
networks
were
also
made
to
improve
spacings.
440
AC
POWER
SUPPLIES
AND
RECHARGEABLE
BATTERIES
Some
versions
of
the
SCALE-TRONIX®
second
generation
scales
employ
an
AC
power
supply,
or
an
AC
supply
with
rechargeable
batteries.
These
are
described
in
more
detail
as
follows:
4.40.1
MODEL
11801
POWER
SUPPLY
This
is
a
small
power
supply
that
is
often
used
in
conjunction
with
a
6.0
volt,
450
Mill-amp
hour
nickel-
cadmium
battery
pack.
22
5002,
5102,
5602,
6002,
6102,
6202, 6502,
6702
