4-Achs Halfpipe Kipper
four axle halfpipe tipper
MAN TGS
Spare parts:
Spare parts can be ordered from us stating the kit
number and the item number on the list of spare parts.
Tools required:
- Phillips screwdriver
- box spanner 2,5mm
- box spanner 3mm
- needle- nosed pliers
- edge cutter
- small hammer
- scalpel
- tweezers
- small flat file
This model was made possible with the kind assistance and approval of the MAN Utility Vehicle Company in Munich.
Please bear in mind that this product is no toy and not suitable for youngsters under the age of 14. Technical details
may be subject to alterations and modifications. No liability is taken for errors and printing mistakes. Reprints and
copies are subject to written and specific permission.
Liability Exclusion / Damage Claims:
The strict observance of the assembly manual as well as handling, installation, operation and servicing of this model
and all components used cannot be supervised by ScaleART. Therefore, ScaleART cannot take on any liability
whatsoever for losses, damages or costs deriving from incorrect use or operation or are connected therewith in any
way.
As far as legally permissible ScaleART`s obligation is to make amendments for whatever legal reason limited to the
invoiced value of ScaleART products directly involved in the incident causing the damage. This does not apply where
ScaleART woud be unrestrictedly liable according to binding legal regulations concerning willful or gross negligence.
Material requiered:
- transparent two-component glue
- cyanoacrylate adhesive
- Loctite screw securing agent
- crepe adhesive tape
1:14,5
approx. 660mm
approx. 172mm
approx. 230mm
60mm
Contents of Kit:
- cab MAN TGS M scale 1:14,5
- stainless steel frame
- front axle suspension with leaf spring
- rear axle suspension with swing springs
- metal front axle
- frame attachments
- tipper body
- aluminium rims and wheels
Acessory Extras:
Assembly parts for remote control model. For item
numbers please refer to list of spare parts.
Technical Data:
scale:
length:
width:
height:
frame width:
General remarks for assembly:
Please read the assembly manual before you start
working and get yourself acquainted with the required
components and tools.
Do not screw the model screws M1,6 and M2 too tight
otherwise they might break. This also applies to all
screws in plastic parts.
Transparent glass parts (panes) must be glued with
two-component glue. Never bring cyanoacrylate
adhesive in contact with any glass parts. For bonding,
these can be fixed with crepe adhesive tape.
Spare parts which have to be bonded with
cyanoacrylate adhesive should never be glued directly
from the tube.We suggest to put the cyanoacrylate
adhesive on some scrap metal sheet or plastic and then
apply it by means of a pin or strip of paper.
